SC to SC OM3 Simplex Patch Cord | 50/125 Multimode LSZH
SC-SC OM3 50/125 multimode simplex patch cord with an LSZH jacket, ≤0.3 dB insertion loss, and specified order length with ±3% tolerance.
Connectors
SC to SC (simplex)
Fiber
OM3 multimode 50/125
Jacket
LSZH (aqua)
Loss
≤0.3 dB insertion loss
Technical Architecture & Functionality
The [Opticis]SSMS-050-XX(OM3) is a simplex (1-core) OM3 multimode fiber patch cord terminated SC to SC, built for clean, dependable optical runs in AV, industrial, and extender-based installs.
This cable uses 50/125 µm OM3 multimode fiber in an aqua LSZH (Low Smoke Zero Halogen) jacket, with an aramid yarn strength member for improved durability. It’s a straightforward, no-drama patch cord for when you just need the fiber to work.
Optical performance is specified with low insertion loss (max 0.3 dB, typ 0.15 dB) and return loss (min 40 dB, typ 45 dB) using UPC-polished ferrules. The specified order length is manufactured with a ±3% tolerance.
Key Engineering Advantages
Made for 1-Fiber Extender Links
A clean SC-SC simplex OM3 patch cord choice for Opticis-style 1-core optical connections.
Low-Loss Optical Performance
Specified insertion loss up to 0.3 dB (typ 0.15 dB) with strong return loss targets for stable links.
LSZH Jacket for Safer Installs
Low Smoke Zero Halogen jacket supports cleaner deployments in indoor and controlled environments.
Durable Construction
Aramid yarn strength member and standard mechanical test coverage help it survive real installations.
Predictable Length Tolerance
The specified order length is manufactured with a ±3% tolerance.
Feature Checklist
- SC to SC termination (simplex / 1-core)
- OM3 multimode 50/125 µm fiber
- LSZH jacket and tight buffer (aqua)
- Low insertion loss: max 0.3 dB (typ 0.15 dB)
- Return loss: min 40 dB (typ 45 dB)
- UPC polished ferrules
- Cable outer diameter: 2.0 ± 0.3 mm
- Max pulling strength: 600 N
- Specified order length with ±3% tolerance
Technical Specifications
Validated performance benchmarks and physical parameters.
- Part Number
- SSMS-050-XX(OM3)
- Fiber Type
- Multimode OM3, 50/125 µm
- Core Count
- Simplex (1-core)
- Connector Type
- SC to SC
- Polish Type
- UPC
- Jacket
- LSZH (Low Smoke Zero Halogen), aqua
- Tight Buffer
- LSZH, 0.90 ± 0.05 mm
- Strength Member
- Aramid yarn
- Cable Outer Diameter
- 2.0 ± 0.3 mm
- Length
- Specified order length ±3%
- Insertion Loss
- Max 0.3 dB (Typ 0.15 dB)
- Return Loss
- Min 40 dB (Typ 45 dB)
- Attenuation (Fiber)
- @850 nm ≤ 3.0 dB/km; @1300 nm ≤ 1.0 dB/km
- Bandwidth (Fiber)
- @850 nm ≥ 1500 MHz·km; @1300 nm ≥ 500 MHz·km
- Max Pulling Strength
- 600 N
Documentation & Drivers
Package Contents
- SSMS-050-XX(OM3) SC-SC OM3 simplex fiber patch cord (1)
Wiring & Connection Diagram
Inspect module pinouts, transmitter/receiver cabling, and power connections.
Target Application Scenarios
Engineered for harsh industrial automation, medical suites, aerospace testing, and command centers where signal integrity is non-negotiable.
Sector Compliance & Use Cases
- Fiber links for **Opticis detachable extenders** and 1-fiber systems
- Control rooms, KVM and AV routing
- Industrial environments where copper noise is a feature, not a bug
- Patch panel interconnects requiring **SC simplex OM3**
